LEtC Smart Charging & Best BESS
Welcome to our tailor-made smart fast charging solutions! We offer advanced 360kW and 480kW Electric Vehicle Supply Equipment (EVSE) designed to meet the demands of modern vehicles. Our Energy Management System (EMS) & Battery Management System (BMS) products ensure optimal performance and efficiency, making charging faster and more. We also offer tailor-made BESS for special purpose, no matter in the next generation AI Data Center UPS BESS, BBU, PDU, CDU or off-grid, VPP, or smart grid integration, we are more than happy to assist you world-wide.
01
480KW EV Charger
Model No.: GE-11-480DC-01
Charging Type: DC fast charging
Outlet Cable Options: C: CCS2, A: CCS1 , J: CHAdeMO, G: GBT
AC Input Power @ 480V 60Hz: 600A, 500KVA
Input Voltage Range: 380/400/480 VAC
Input Frequency: 50 Hz or 60 Hz
DC Output Power Rating: 480 kW
DC Output Voltage 150-1000 Vdc
Connectivity : Ethernet, 4G
User Authentication: APP or RFID Card (OPT)
Platform Protocols: Proprietary and OCPP 1.6J
02
360KW EV Charger
Model No.: GE-11-360DC-01
Charging Type: DC fast charging
Outlet Cable Options: Double Outlets (CCS1+NACS)
AC Input Power: 600A
Input Voltage Range: 380/400/480 VAC
Input Frequency: 50 Hz or 60 Hz
DC Output Power Rating: 360 kW
DC Output Voltage 150-1000 Vdc
Connectivity : Ethernet, WIFI, 4G
User Authentication: APP or RFID Card, POS Machine (OPT)
Platform Protocols: OCPP 1.6J
03
Battery Management System (BMS)
Battery Management System (BMS) design focuses on essential features to ensure optimal performance and safety. elements include overcharge, overdischarge, and overcurrent protection, which align with the existing 3C appliance standards. A short circuit detector is implemented, as traditional overcurrent detection is inadequate for high C-rate batteries. Additionally, a detect delay circuit is necessary to manage voltage drops during high current demand, while maintaining voltage and current accuracy consistent with previous models. The cell balance circuit is enhanced with an MCU for control and measurement, ensuring effective balancing and accuracy, all while maintaining lower consumption current.
04
BESS & PCS
BESS Specification
-
Rated energy : 5015kWh
-
Nominal Voltage : 1331.2V
-
Charge/Discharge Power : 2500kW
-
Charge/Diacharge Efficiency : 94%
-
Thermal Management Method: Liquid Cooling/Heating
PCS Specification
-
Nominal Power : 640 kVA (4 x 160 kVA) @720~1200Vdc
-
AC Voltage : 400 (-15%~15%) Vac
-
DC Voltage Range : 720 V~1500 V, > 1200 V derating to 90%
-
AC Current : 924 A (4 x 231 A)
-
DC Max Current : 920 A (4 x 230 A)
05
Energy Management System (EMS)
Building our cloud-based Energy Management System (EMS) electric vehicle (EV) charging stations. As the demand for carbon reduction grows, the need for efficient and intelligent charging solutions is more critical than ever. Our EMS integrates charging piles with renewable energy sources like wind, hydro, and solar, alongside battery energy storage systems (BESS) and advanced AIoT technologies. This innovative platform empowers site operators to deliver reliable charging services while ensuring power safety and optimal energy usage.
